When the crushing machine begin to operate, the motor drives the rotor to spin at high speed, materials are fed into the crushing cavity evenly, and then be impacted, cut and tore by high speed spinning hammerhead till they are completely crushed. Meanwhile, the gravity action of materials forces them to crash the baffle and grate bars on the frame. Materials with particle size smaller than the screen size will pass the sieve plate while those with bigger particle size are stopped on the plate and will continue to be impacted and grounded by the hammer until they are crushed to the required particle size. Finally, crushed materials will be discharged from the hammer crusher through the sieve plate.
| Model | Feeding size (mm) | Discharging granularity (mm) | Output (t/h) | Motor Power (kW) | Dimensions (L × W × H) (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 2PG-400×250 | ≤ 25 | 2-8 | 5-10 | 11 | 1215 × 834 × 830 | 1100 |
| 2PG-610×400 | ≤ 40 | 1-20 | 13-40 | 30 | 3700 × 1600 × 1100 | 3500 |
| 2PG-750×500 | ≤ 40 | 2-20 | 20-55 | 37 | 2530 × 3265 × 1316 | 12250 |
| 2PG-900×500 | ≤ 40 | 3-40 | 60-125 | 44 | 2750 × 1790 × 2065 | 14000 |
It could reduce the particle size and improve the crushing characteristics of the materials to be crushed. The crushed products are mostly cubes in the shapes with less needle-like content without tension or cracks.
The tooth roller of the roller crusher is made of high-yield wear-resistant materials, which has a strong impact on high wear resistance. It has the advantages of small loss and low failure rate when crushing materials, reducing the maintenance costs in the later stage.
The roller crusher is equipped with advanced environmental protection devices. The whole production process has low noise, low dust, and low pollution, which meets the requirements of national environmental protection.
